系列:MA52
名稱:分離式磁電編碼器
外形尺寸:52mmX18mm;
額定功率:DC 5V 15mA;
分辨率:128個脈沖/360°
定位點數:24 個;
工作溫度:-25℃~90℃;
旋轉壽命:50000次以上;
按壓壽命:100000次;
分離式按壓旋鈕控制器;無需焊接或插拔,定位放置就可使用
主要適應用在集成灶等其它家電類產品
一、MECHANICAL CHARACTERISTIC 機械特性
1、Rotational torque 旋轉力矩 :100-300gf.cm
2、Step angle 每段角度:15°±2°
3、Operating force of switch開關作動力:350~650gf
二、ELECTRICAL CHARACTERISTIC 電氣特性
1、Rating power 額定功率 :DC 5V 15mA
2、Encoder pulses 脈沖數:100 脈沖
3、Number of detent 定位點數:24 detents
4、Insulation resistance 絕緣阻抗:100M? 1 Minute at DC 250V
5、Dielectric voltage 耐電壓:1 Minute at AC 300V
三、ENDURANCE CHARACTERISTIC 耐久特性
1、Rotational life 旋轉壽命:50,000 cycles Min
2、Switch operating life開關壽命特性:100,000 cycles Min
Note:In this catalog,if some parame ters lr drawings are different from the "Approval sheet",it's subject to the "Approval sheet".
注明:如說明書與承認書規格參數、圖面有異,均以承認書為準。
