RJ26 4-direction lateral switch

Series：

Format：See the following profile

Specifications　　

Switch model：	RJ26 series
Applications：	Car seats, game consoles.
Product Features:	4-direction lateral switches with no pressing function; Available in two terminals (NO) or three terminals (NC and NO) with each switch; Good operation feel with stable performance; Wide application field and high endurance.
Main Specifications:	Rated power: DC24V 10A; Contact resistance: 30mΩ Operating force: 650±200gf Electrical contact travel: 1.2±0.3mm Insulation resistance: 100MΩ Dielectric voltage: AC500V 10mA Operating temperature: -40℃～85℃; Operating life: 25,000 cycles Min

RJ26 Product Specifications

ONE、MECHANICAL CHARACTERISTIC

1. Operating Force: 650±200gf

2. Force Difference: 25% Max

3. Electrical contact travel: 1.2±0.3mm

4. Total Travel: 2.2mm Max

5. Travel Difference: 0.3mm Min

6. Shaft Strength: 10kg Min

TWO、ELECTRICAL CHARACTERISTIC
1. Contact resistance: 30mΩ Max

2. Insulation resistance: 100MΩ

3. Dielectric Voltage: AC 500V 10mA

THREE、ENDURANCE CHARACTERISTIC

1. Operating Life: 25,000 cycles Min

Note: In this catalog, if some parameters or drawings are different from the "Approval sheet", it's subject to the "Approval sheet".
